NEW
D5062
- DC-MHS M-DNO M-FLW HPM
- Dual Intel® Xeon® 6700 series processors, TDP up to 350W
- (32) DDR5 RDIMM, 8 channels per CPU(2DPC), up to 6400MT/s(1DPC) and 5200MT/s(2DPC)
- (5) PCIe 5.0 x16 SFF-TA-1033 MXIO slots
- (8) Far-Side PCIe5.0 x8 MCIO 8i connectors
- (2) 2280/22110 PCIe 5.0 x2 NVMe M.2 ports
- (2) E1.S 9.5mm PCIe 5.0 x4 ports
- (1) PCIe 5.0 x16 OCP3.0 slot (NCSI supported)
NEW
D4056
- DC-MHS M-DNO Type-4 HPM
- Single AMD EPYC™ 9004/9005 Series processor, up to TDP 500W
- (24) DDR5 RDIMM, 12 channels(2DPC), up to 5200MT/s
- (2) PCIe 5.0 x16 SFF-TA-1033 MXIO slots
- (8) PCIe5.0 x8 MCIO 8i connectors
- (2) 2280/22110 PCIe 3.0 x2 NVMe M.2 ports
- (2) PCIe 5.0 x16 OCP3.0 slots (NCSI supported)
D3066
- DC-MHS M-DNO Type-4 HPM
- Single Intel® Xeon® 6700 series processor, TDP up to 350W
- (16) DDR5 RDIMM, 8 channels(2DPC), up to 6400MT/s(1DPC) and 5200MT/s(2DPC)
- (3) PCIe 5.0 x16 SFF-TA-1033 MXIO slots
- (6) PCIe5.0 x8 MCIO 8i connectors
- (2) 2280/22110 PCIe 5.0 x2 NVMe M.2 ports
- (2) PCIe 5.0 x16 OCP3.0 slots (NCSI supported)
NEW
D4051
- DC-MHS M-DNO Type-2 HPM
- Single AMD EPYC™ 9004/9005 Series processor, up to TDP 500W
- (12) DDR5 RDIMM, 12 channels(1DPC), up to 6000MT/s
- (6) Near-Side PCIe 5.0 x8 MCIO-8i connectors
- (4) Far-Side PCIe 5.0 x8 MCIO-8i connectors
- (2) 2280/22110 PCIe 5.0 x2 NVMe M.2 ports
- (1) PCIe 5.0 x16 OCP3.0 slot (NCSI supported)
NEW
D3071
- DC-MHS M-DNO Type-2 HPM
- Single Intel® Xeon® 6900 series processors, TDP up to 500W
- (12) DDR5 RDIMM, 12 channels(1DPC), up to 6400MT/s
- (4) Near-Side PCIe 5.0 x8 MCIO-8i connectors
- (5) Far-Side PCIe 5.0 x8 MCIO-8i connectors
- (2) 2280/22110 PCIe 5.0 x2 NVMe M.2 ports
- (1) PCIe 5.0 x16 OCP3.0 slot (NCSI supported)
NEW
D3061
- DC-MHS M-DNO Type-2 HPM
- Single Intel® Xeon® 6700 series processor, TDP up to 350W
- (16) DDR5 RDIMM, 8 channels(2DPC), up to 6400MT/s
- (4) Near-Side PCIe 5.0 x8 MCIO-8i connectors
- (5) Far-Side PCIe 5.0 x8 MCIO-8i connectors
- (2) 2280/22110 PCIe 5.0 x2 NVMe M.2 ports
- (1) PCIe 5.0 x16 OCP3.0 slot (NCSI supported)
NEW
- Extended uATX, 9.6" x 10.5"
- Single Socket SP6, supports AMD EPYC™ 8004 Series processors
- (8) DIMM slots, 2DPC/1DPC, upto 4800/3600MT/s, RDIMM
- (2) 25G SFP28 Ports (Broadcom BCM57502) and (2) 1000Base-T(Intel® I210AT) Ports
- (16) SATA3.0 ports or (6) PCIe5.0 x4 NVMe Ports
- (2) 2280 PCIe 5.0 x4 NVMe M.2 ports
- (1) 1000Base-T Dedicated server management port
- ASPEED AST2600 with IPMI & DMTF Redfish support
- Supports ATX PSU
HOT
D3052
- uATX, 9.6" x 9.6"
- Single socket AM5, AMD Ryzen™ 7000 Series and EPYC™ 4004 Series Processor
- (4) DDR5 DIMM slots,2DPC, up to 5200MT/s, ECC/non-ECC UDIMM
- (2) 25G SFP28 Ports (Intel® E810-XXVAM2)
- (4) SATA3.0 ports (Supporting one SATADOM) , (2) SATA2.0 ports
- (1) 2280/22110 PCIe4.0 x4 NVMe M.2 Ports
- (1) 1000Base-T Dedicated Server Management Port
- ASPEED AST2600 with IPMI & DMTF Redfish Support
- Supports ATX PSU
- uATX, 9.6" x 9.6"
- Single socket, LGA1700, Intel® Xeon® E-2400, C266 PCH
- (4) DDR5 DIMM slots,2DPC, up to 4800MT/s, ECC/non-ECC UDIMM
- (2) 25G SFP28 (Intel® E810XXVAM2) Ports
- Up to (8) SATA 3.0 or (4) PCIe4.0/3.0 x4 NVMe Ports
- (1) 2280/22110 PCIe4.0 x4 NVMe M.2 Ports
- (1) 1000Base-T Dedicated Server Management Port
- ASPEED AST2600 with IPMI & DMTF Redfish Support
- Supports ATX PSU
