NEW
CX270-S5062
CX270-S5062
  • 2U (DC-MHS architecture)
  • Dual Intel® Xeon® 6700 series processors, TDP up to 350W
  • (32) DDR5 RDIMM, 8 channels per CPU(2DPC), up to 6400MT/s(1DPC) and 5200MT/s(2DPC)
  • (8) or (24) Front hot-swap 2.5" U.2 PCIe 5.0 x4 NVMe drive bays
  • (2) Rear hot-swap E1.S 9.5mm PCIe 5.0 x4 NVMe drive bays
  • (2) 2280/22110 PCIe 5.0 x2 NVMe M.2 ports
  • Up to (6) PCIe 5.0 x16 expansion slots
  • (1) PCIe 5.0 x16 OCP3 NIC Mezzanine slot (NCSI supported)
  • (1) 1000Base-T Dedicated Server Management port with:
  • ASPEED AST2600 with IPMI 2.0 & DMTF Redfish support
  • Dual BIOS & BMC
  • TPM2.0 and Hardware Root of Trust module are supported as optional
NEW
CX271-S3066
CX271-S3066
  • 2U (DC-MHS architecture)
  • Single Intel® Xeon® 6700 series processor, TDP up to 350W
  • (16) DDR5 RDIMM, 8 channels(2DPC), up to 6400MT/s(1DPC) and 5200MT/s(2DPC)
  • (8) or (24) Front hot-swap 2.5" U.2 PCIe 5.0 x4 NVMe drive bays
  • (2) 2280/22110 PCIe 5.0 x2 NVMe M.2 ports
  • Up to (3) PCIe 5.0 x16 expansion slots
  • (2) PCIe 5.0 x16 OCP3 NIC Mezzanine slot (NCSI supported)
  • (1) 1000Base-T Dedicated Server Management port with:
  • ASPEED AST2600 with IPMI 2.0 & DMTF Redfish support
  • Dual BIOS & BMC
  • TPM2.0 and Hardware Root of Trust module are supported as optional
NEW
CX271-S4056
CX271-S4056
  • 2U (DC-MHS architecture)
  • Single AMD EPYC™ 9004/9005 Series processor, TDP up to 500W
  • (24) DDR5 RDIMM, 12 channels(2DPC), up to 5200MT/s
  • (8) or (24) Front hot-swap 2.5" U.2 PCIe 5.0 x4 NVMe drive bays
  • (2) 2280/22110 PCIe 3.0 x2 NVMe M.2 ports
  • Up to (2) PCIe 5.0 x16 expansion slots
  • (1) 1000Base-T Dedicated Server Management port with:
  • ASPEED AST2600 with IPMI 2.0 & DMTF Redfish support
  • Dual BIOS & BMC
  • TPM2.0 and Hardware Root of Trust module are supported as optional
NEW
CD270-S3071-X2
CD270-S3071-X2
  • 2U2N (DC-MHS architecture)
  • Single Intel® Xeon® 6900 series processor, TDP up to 500W, per node
  • (12) DDR5 RDIMM, 12 channels(1DPC), up to 6400MT/s, per node
  • (6) Front hot-swap 2.5" U.2 PCIe 5.0 x4 NVMe drive bays per node
  • (2) 2280/22110 PCIe 5.0 x2 NVMe M.2 ports per node
  • (1) FHHL PCIe 5.0 x16 slot per node
  • (1) 1000Base-T Dedicated Server Management port per node with:
  • ASPEED AST2600 with IPMI 2.0 & DMTF Redfish support
  • Dual BIOS & BMC
  • TPM2.0 and Hardware Root of Trust module are supported as optional
NEW
CD270-S3061-X2
CD270-S3061-X2
  • 2U2N (DC-MHS architecture)
  • Single Intel® Xeon® 6700 series processor, TDP up to 350W, per node
  • (16) DDR5 RDIMM, 8 channels(2DPC), up to 6400MT/s, per node
  • (6) Front hot-swap 2.5" U.2 PCIe 5.0 x4 NVMe drive bays per node
  • (2) 2280/22110 PCIe 5.0 x2 NVMe M.2 ports per node
  • (1) FHHL PCIe 5.0 x16 slot per node
  • (1) 1000Base-T Dedicated Server Management port per node with:
  • ASPEED AST2600 with IPMI 2.0 & DMTF Redfish support
  • Dual BIOS & BMC
  • TPM2.0 and Hardware Root of Trust module are supported as optional
NEW
CD270-S3061-X4
CD270-S3061-X4
  • 2U4N (DC-MHS architecture)
  • Single Intel® Xeon® 6700 series processor, TDP up to 350W, per node
  • (16) DDR5 RDIMM, 8 channels(2DPC), up to 6400MT/s, per node
  • (3) Front hot-swap 2.5" U.2 PCIe 5.0 x4 NVMe drive bays per node
  • (2) 2280/22110 PCIe 5.0 x2 NVMe M.2 ports per node
  • (1) 1000Base-T Dedicated Server Management port per node with:
  • ASPEED AST2600 with IPMI 2.0 & DMTF Redfish support
  • Dual BIOS & BMC
  • TPM2.0 and Hardware Root of Trust module are supported as optional
NEW
CD270-S4051-X4
CD270-S4051-X4
  • 2U4N (DC-MHS architecture)
  • Single AMD EPYC™ 9004/9005 Series processor, up to TDP 400W, per node
  • (12) DDR5 RDIMM, 12 channels(1DPC), up to 6000MT/s, per node
  • (3) Front hot-swap 2.5" U.2 PCIe 5.0 x4 NVMe drive bays per node
  • (2) 2280/22110 PCIe 3.0 x2 NVMe M.2 ports per node
  • (1) 1000Base-T Dedicated Server Management port per node with:
  • ASPEED AST2600 with IPMI 2.0 & DMTF Redfish support
  • Dual BIOS & BMC
  • TPM2.0 and Hardware Root of Trust module are supported as optional
NEW
CX170-S5062
CX170-S5062
  • 1U (DC-MHS architecture)
  • Dual Intel® Xeon® 6700 series processors, TDP up to 350W
  • (32) DDR5 RDIMM, 8 channels per CPU(2DPC), up to 6400MT/s(1DPC) and 5200MT/s(2DPC)
  • (12) Front hot-swap 2.5" U.2 PCIe 5.0 x4 NVMe drive bays
  • (2) Rear hot-swap E1.S 9.5mm PCIe 5.0 x4 NVMe drive bays
  • (2) 2280/22110 PCIe 5.0 x2 NVMe M.2 ports
  • (2) PCIe 5.0 x16 expansion slots
  • (1) PCIe 5.0 x16 OCP3 NIC Mezzanine slot (NCSI supported)
  • (1) 1000Base-T Dedicated Server Management port per node with:
  • ASPEED AST2600 with IPMI 2.0 & DMTF Redfish support
  • Dual BIOS & BMC
  • TPM2.0 and Hardware Root of Trust module are supported as optional
NEW
CD270-S4051-X2
CD270-S4051-X2
  • 2U2N (DC-MHS architecture)
  • Single AMD EPYC™ 9004/9005 Series processor, up to TDP 500W, per node
  • (12) DDR5 RDIMM, 12 channels(1DPC), up to 6000MT/s, per node
  • (6) Front hot-swap 2.5" U.2 PCIe 5.0 x4 NVMe drive bays per node
  • (2) 2280/22110 PCIe 3.0 x2 NVMe M.2 ports per node
  • (1) FHHL PCIe 5.0 x16 slot per node
  • (1) 1000Base-T Dedicated Server Management port per node with:
  • ASPEED AST2600 with IPMI 2.0 & DMTF Redfish support
  • Dual BIOS & BMC
  • TPM2.0 and Hardware Root of Trust module are supported as optional
